Cast iron V pulley, 100 mm diameter, single groove, bored 16 mm with a 5 mm keyway. Ships from Glen Waverley.
Shaft and key
Shaft fit: 16 mm, key 5 mm. A pulley bored for a different shaft will not sit true, so check before ordering. Made for 5/8" (16 mm) shafts.
About this pulley
With one groove it takes a single A-section belt, the usual set-up for smaller motors. Cast iron is heavy and hard-wearing, and its weight helps smooth out the drive.
Working out a belt drive: multiply motor rpm by the driving pulley's pitch diameter, then divide by the driven pulley's pitch diameter. Pitch diameter is a little less than the 100 mm outside diameter.
Same 16 mm bore, other sizes: 50 mm single, 50 mm double, 70 mm single, 70 mm double, 90 mm single, 90 mm double, 100 mm double, 120 mm single.
Specifications
OD
100 mm
Belt grooves
1 (single)
Keyway
5 mm
Construction
Cast iron
Belt section
A-section V-belt
Bore
16 mm (5/8")
Good to know
- Never fit or adjust a pulley with power available to the motor.
- Push the pulley fully home on the shaft before tightening.
- Replace multiple belts as a matched set.
- A guard over the belt and pulleys is required before use.
Delivery and warranty
Dispatched from Glen Waverley, VIC. Enter your address at checkout for postage. Returns and warranty follow our Returns, Refunds & Warranty Policy.
Measuring up a replacement? We can help: 0401 634 280, hankemotors@gmail.com.
