Double-groove belt pulley for a 16 mm shaft: cast iron, 50 mm across. In stock at Glen Waverley, VIC.
Bore and shaft size
Shaft fit: 16 mm, key 5 mm. A pulley bored for a different shaft will not sit true, so check before ordering. 16 mm is the metric equivalent of 5/8", a common shaft size on imported and older motors.
Single, double or triple groove?
Double grooves mean two belts and roughly twice the grip of one. Cast iron is heavy and hard-wearing, and its weight helps smooth out the drive.
Pulley speed ratio: driven rpm = motor rpm × (driver diameter ÷ driven diameter). Calculate with pitch diameters rather than outside diameters for the exact result.
Need a different diameter for a 16 mm shaft? Try 50 mm single, 70 mm single, 70 mm double, 90 mm single, 90 mm double, 100 mm single, 100 mm double, 120 mm single.
Specifications
Outside diameter
50 mm
Bore
16 mm (5/8")
Belt section
A
Construction
Cast iron
Key width
5 mm
Number of grooves
2 (double)
Before you install
- Isolate the motor before working on the drive.
- Line the two pulleys up with a straight edge so the belts run true; misalignment wears belts fast.
- Do not over-tighten the belt; it loads the motor bearings.
- A guard over the belt and pulleys is required before use.
Postage, returns and warranty
Australia-wide delivery from our Glen Waverley store; postage appears at checkout. Our Returns, Refunds & Warranty Policy explains warranty and returns.
Measuring up a replacement? We can help: 0401 634 280, hankemotors@gmail.com.
