Worm geared motor, 2.2 kW / 3 HP, 415 V three phase, gearbox size 110 with a hollow output (35 mm). Available ratios 15:1 to 60:1. Ships from Glen Waverley.
Ratio menu explained
The motor runs at 1400 rpm. Divide by the ratio to get the output speed:
15:1, 42 mm output
about 93 rpm
20:1, 42 mm output
about 70 rpm
25:1, 42 mm output
about 56 rpm
30:1, 42 mm output
about 47 rpm
40:1, 42 mm output
about 35 rpm
50:1, 42 mm output
about 28 rpm
60:1, 42 mm output
about 23 rpm
Calculated from nameplate speed. Loaded speed is a little lower.
Maximum output torque is listed as 648 Nm. Lower ratios give more speed but less torque than that figure; check with us if your load is close to it.
Power supply
Needs 415 V three phase, or a single-to-three phase VFD on a 240 V site. The VFD also gives you variable output speed.
Already have a motor?
Have a motor already? Browse the gearbox-only range and match the IEC frame and shaft of your motor.
Key figures
Motor power
2.2 kW / 3 HP
Voltage
415 V three phase, 50 Hz
Motor speed
1400 rpm
Gear unit
Worm, size 110
Hollow output
35 mm hollow shaft
Peak torque (listed)
648 Nm
Duty class
S1 (continuous)
Before you install
- For hoisting or holding, add a brake; the worm alone is not enough.
- Restrain the gearbox housing so it cannot rotate; hollow-shaft mounting needs a torque arm.
- The motor must be connected by a licensed electrician.
Postage, returns and warranty
Australia-wide delivery from our Glen Waverley store; postage appears at checkout. Our Returns, Refunds & Warranty Policy explains warranty and returns.
Not sure which ratio? Tell us the speed you need at the output: 0401 634 280 or hankemotors@gmail.com.
