Worm geared motor, 0.37 kW / 0.5 HP, 240 V single phase, gearbox size 063 with a hollow output (25 mm). Available ratios 25:1 to 60:1. Ships from Glen Waverley.
Ratio menu explained
Output speed is the motor's 1400 rpm divided by the ratio you choose:
25:1, 25 mm output
about 56 rpm
30:1, 25 mm output
about 47 rpm
40:1, 25 mm output
about 35 rpm
50:1, 25 mm output
about 28 rpm
60:1, 25 mm output
about 23 rpm
50:1, 35 mm output
about 28 rpm
60:1, 35 mm output
about 23 rpm
Nominal speeds; under load the motor slows slightly.
Maximum output torque is listed as 129 Nm. Lower ratios give more speed but less torque than that figure; check with us if your load is close to it.
Supply and speed control
The motor runs on standard 240 V single phase power, so it suits sites without three phase. Speed is fixed by the ratio you choose.
Where it is used
Right-angle worm drives are popular where space is tight: the motor sits at 90 degrees to the driven shaft, which keeps the whole unit compact.
Motor and gearbox data
Rated power
0.37 kW / 0.5 HP
Power supply
240 V single phase, 50 Hz
Duty class
S1 (continuous)
Output torque, max.
129 Nm
Hollow output
25 mm hollow shaft
Gearbox
Worm, size 063
Motor speed
1400 rpm
Before you install
- Do not rely on the worm to hold a suspended load; fit a brake.
- Restrain the gearbox housing so it cannot rotate; hollow-shaft mounting needs a torque arm.
- Wiring is a job for a licensed electrician.
Shipping
Freight is worked out at checkout and the geared motor leaves from Glen Waverley, VIC. See the Returns, Refunds & Warranty Policy for warranty.
Send us the job details and we will suggest a ratio: hankemotors@gmail.com, 0401 634 280.
