Size 063 worm gearbox with a 0.25 kW 240 V single phase motor and 25 mm hollow output, supplied assembled. Choose one of 7 ratios below. In stock at Glen Waverley, VIC.
Ratios and output speeds
Output speed is the motor's 1400 rpm divided by the ratio you choose:
40:1, 25 mm output
about 35 rpm
50:1, 25 mm output
about 28 rpm
60:1, 25 mm output
about 23 rpm
80:1, 25 mm output
about 17.5 rpm
40:1, 35 mm output
about 35 rpm
50:1, 35 mm output
about 28 rpm
60:1, 35 mm output
about 23 rpm
Rounded figures; real speed drops a few percent at full load.
Listed peak output torque is 100 Nm. If your job needs close to that at a low ratio, ask us to check the sizing.
Power supply
Single phase 240 V means it can run where only a normal supply is available. For adjustable speed, choose the three phase version with a 240 V input VFD.
Connecting the load
With a hollow output of 25 mm the gearbox can sit directly on the machine shaft. A little anti-seize on the shaft makes it much easier to remove later.
Specifications
Power
0.25 kW / 0.34 HP
Supply
240 V single phase, 50 Hz
Motor rpm
1400 rpm
Reducer
Worm, size 063
Output shaft
25 mm hollow shaft
Max. output torque
100 Nm
Duty class
S1 (continuous)
Before you install
- For hoisting or holding, add a brake; the worm alone is not enough.
- Restrain the gearbox housing so it cannot rotate; hollow-shaft mounting needs a torque arm.
- The motor must be connected by a licensed electrician.
Delivery and warranty
Australia-wide delivery from our Glen Waverley store; postage appears at checkout. Our Returns, Refunds & Warranty Policy explains warranty and returns.
Questions about torque or speed? 0401 634 280 or hankemotors@gmail.com.
