3 HP worm gear motor, 240 V single phase. Size 090 gearbox with a 35 mm hollow output. Pick from 7 ratios; the slowest gives about 35 rpm. Ships from Glen Waverley.
Ratio menu explained
Speeds below assume the motor's 1400 rpm:
7.5:1, 35 mm output
about 187 rpm
10:1, 35 mm output
about 140 rpm
15:1, 35 mm output
about 93 rpm
20:1, 35 mm output
about 70 rpm
25:1, 35 mm output
about 56 rpm
30:1, 35 mm output
about 47 rpm
40:1, 35 mm output
about 35 rpm
Figures are motor speed ÷ ratio, rounded.
Listed peak output torque is 456 Nm. If your job needs close to that at a low ratio, ask us to check the sizing.
Supply and speed control
Single phase 240 V means it can run where only a normal supply is available. For adjustable speed, choose the three phase version with a 240 V input VFD.
Typical jobs
Right-angle worm drives are popular where space is tight: the motor sits at 90 degrees to the driven shaft, which keeps the whole unit compact.
Key figures
Motor power
2.2 kW / 3 HP
Power supply
240 V single phase, 50 Hz
Input speed
1400 rpm
Gear unit
Worm, size 090
Hollow output
35 mm hollow shaft
Output torque, max.
456 Nm
Duty
S1 (continuous)
Safety and fitting
- For hoisting or holding, add a brake; the worm alone is not enough.
- Guard the output shaft and anything connected to it.
- Have a licensed electrician wire the motor.
Shipping and warranty
Dispatched from Glen Waverley, VIC. Enter your address at checkout for postage. Returns and warranty follow our Returns, Refunds & Warranty Policy.
Call 0401 634 280 or email hankemotors@gmail.com and we will help choose the ratio and size.
