5.5kw 7.5HP 2800rpm shaft 38mm Electrical motor single-phase 240v
$436.00
In Stock
Sold out
Add to wishlist
Added to wishlist
100% ORIGINAL AND QUALITY
12 MONTHS GUARANTEE
- description
- Technical parameters
- Installation dimension
- Bearing Size
- Useful Downloads
- Related Policy
- Power: 5.5kw/7.5HP
- Model: GMYL132M-2
- Single-Phase: 240v
- Maximum Amps Draw: 31.5Amps
- Speed: 2800rpm (2 Pole)
- Shaft Size: 38mm
- Light Weight
- Please click download for the full measurement of this motor.
- We have single and three-phase electrical motor. ( 0.18kw-315kw )(2,4,6 and 8 pole)
- We also have this product selling on our ebay store
CSCR (Capacitor starts and capacitor runs) Motor
Circuit breaker installed and dedicated for the particular single phase motor at no extra cost!
TEFC (Total Enclosed Fan Cooled)
Reverse Motor: All single phase & three phase motors are reversible!
Brand new motor. One year warranty.
| TECHNICAL DATA OF GMYL SERIES | |||||||||||||
| Franme reference and size | rated power | Full load sreed in revolutions per minute | Full load current at rated voltage | Exiciter Voltage | Efficiency | Power factor | Direct on line staring torque ratio | Direct on line pull out torque ratio | Direct on line starting current ratio | Mean sound pressure level @1m on no load | Start Capacitor | Running Capacitor | Weight |
| Type | Output | Speed | Amps | Voltage | EFF. | P.F. | LRT/RLT | BDT/RLT | LRA/RLA | Noise | (μf/v) | (μf/v) | Weight |
| (KW) | (r/min) | (A) | (V) | (%) | Cosφ | LwdB(A) | (Kg) | ||||||
| GMYL711-2 | 0.37 | 2800 | 2.7 | 240 | 67 | 0.92 | 1.8 | 1.6 | 5.5 | 72 | 50/250 | 8/450 | 10 |
| GMYL712-2 | 0.55 | 2800 | 3.9 | 240 | 70 | 0.92 | 1.8 | 1.6 | 5.5 | 72 | 100/250 | 15/450 | 11 |
| GMYL711-4 | 0.25 | 1400 | 2 | 240 | 62 | 0.92 | 1.7 | 1.6 | 5.0 | 67 | 75/250 | 15/450 | 9 |
| GMYL712-4 | 0.37 | 1400 | 2.8 | 240 | 65 | 0.92 | 1.7 | 1.6 | 5.0 | 67 | 75/250 | 15/450 | 10 |
| GMYL801-2 | 0.75 | 2800 | 4.9 | 240 | 73 | 0.95 | 1.8 | 1.6 | 5.5 | 75 | 100/250 | 25/450 | 14 |
| GMYL802-2 | 1.1 | 2800 | 7 | 240 | 75 | 0.95 | 1.8 | 1.6 | 5.5 | 75 | 100/250 | 30/450 | 15 |
| GMYL801-4 | 0.55 | 1400 | 3.95 | 240 | 69 | 0.92 | 1.7 | 1.6 | 5.0 | 70 | 100/250 | 15/450 | 13 |
| GMYL802-4 | 0.75 | 1400 | 5.05 | 240 | 71 | 0.95 | 1.7 | 1.6 | 5.0 | 70 | 100/250 | 25/450 | 14 |
| GMYL90L1-2 | 1.5 | 2800 | 9.4 | 240 | 76 | 0.95 | 1.8 | 1.6 | 5.5 | 78 | 200/250 | 40/450 | 22 |
| GMYL90L2-2 | 2.2 | 2800 | 13.7 | 240 | 77 | 0.95 | 1.7 | 1.6 | 5.5 | 78 | 300/250 | 50/450 | 24 |
| GMYL90L1-4 | 1.1 | 1400 | 7.3 | 240 | 72 | 0.95 | 1.7 | 1.6 | 5.0 | 73 | 150/250 | 30/450 | 21 |
| GMYL90L2-4 | 1.5 | 1400 | 9.7 | 240 | 74 | 0.95 | 1.7 | 1.6 | 5.0 | 73 | 200/250 | 40/450 | 23 |
| GMYL100L-2 | 3 | 2222 | 18.2 | 240 | 79 | 0.95 | 1.7 | 1.6 | 6.0 | 83 | 350/250 | 55/450 | 24 |
| GMYL100L1-4 | 2.2 | 1400 | 13.9 | 240 | 76 | 0.95 | 1.7 | 1.6 | 5.0 | 78 | 300/250 | 50/450 | 32 |
| GMYL100L2-4 | 3 | 1400 | 18.4 | 240 | 78 | 0.95 | 1.7 | 1.6 | 5.0 | 78 | 350/250 | 55/450 | 33 |
| GMYL112M-2 | 3.7 | 2800 | 22.1 | 240 | 80 | 0.95 | 1.7 | 1.6 | 6.0 | 83 | 350/250 | 60/450 | 46 |
| GMYL112M-4 | 3.7 | 1400 | 20.8 | 240 | 78 | 0.95 | 1.7 | 1.6 | 5.0 | 78 | 350/250 | 60/450 | 44 |
| GMYL132M-2 | 5.5 | 2800 | 31.5 | 240 | 78 | 0.95 | 1.7 | 1.6 | 5.0 | 78 | 350/250 | 75/450 | 55 |
| GMYL132M-4 | 5.5 | 1400 | 32.4 | 240 | 78 | 0.95 | 1.7 | 1.6 | 5.0 | 78 | 350/250 | 75/450 | 55 |
| MOUNTING DATA FOR GM | ||||||||||||||||||||
| Frame with feet and end-shield with flange (IM B35) | ||||||||||||||||||||
| FRAME SIZE | POLES | A | B | C | D | E | F | G | H | K | P | N | M | S | T | AB | BB | AC | HD | L |
| 63 | 2、4 | 100 | 80 | 40 | 11 | 23 | 4 | 8.5 | 63 | 7 | 140 | 95 | 115 | 10 | 3 | 135 | 100 | 120 | 182 | 217 |
| 71 | 2、4 | 80 | 80 | 45 | 14 | 30 | 5 | 11 | 71 | 7 | 160 | 110 | 130 | 10 | 3.5 | 150 | 112 | 135 | 190 | 250 |
| 80 | 2、4 | 125 | 100 | 50 | 19 | 40 | 6 | 15.5 | 80 | 10 | 200 | 130 | 165 | 12 | 3.5 | 165 | 125 | 160 | 215 | 290 |
| 90S | 2、4 | 140 | 100 | 56 | 24 | 50 | 8 | 20 | 90 | 10 | 200 | 130 | 165 | 12 | 3.5 | 180 | 156 | 175 | 230 | 315 |
| 90L | 2、4 | 140 | 125 | 56 | 24 | 50 | 8 | 20 | 90 | 10 | 200 | 130 | 165 | 12 | 3.5 | 180 | 156 | 175 | 230 | 340 |
| 100L | 2、4 | 160 | 140 | 63 | 28 | 60 | 8 | 24 | 100 | 12 | 250 | 180 | 215 | 15 | 4 | 205 | 172 | 195 | 250 | 425 |
| 112M | 2、4 | 190 | 140 | 70 | 28 | 60 | 8 | 24 | 112 | 12 | 250 | 180 | 215 | 15 | 4 | 245 | 181 | 215 | 285 | 450 |
| 132S | 2、4 | 216 | 140 | 89 | 38 | 80 | 10 | 33 | 132 | 12 | 300 | 230 | 26B | 15 | 4 | 280 | 186 | 255 | 335 | 550 |
| 132M | 2、4 | 216 | 178 | 89 | 38 | 80 | 10 | 33 | 132 | 12 | 300 | 230 | 265 | 15 | 4 | 260 | 224 | 259 | 330 | 525 |
| Frame Size | Poles | Drive End | Non-Drive End |
| International type | Internationat type | ||
| 63 | 2-4 | 6201-2RZ | 6201-2RZ |
| 71 | 2-4 | 6202-2RZ | 6202-2RZ |
| 80 | 2-4 | 6204-2RZ | 6204-2RZ |
| 90 | 2-6 | 6205-2RZ | 6205-2RZ |
| 100 | 2-6 | 6206-2RZ | 6206-2RZ |
| 112 | 2-6 | 6306-2RZ | 6306-2RZ |
| 132 | 2-6 | 6308-2RZ | 6308-2RZ |
